Maximum cultivation depth, two types of protection.

The TERRALAND TN_PROFI chisel plough cultivates soil at a depth of up to 25.6 inches. The tine protection is mechanical using shear bolts, or hydraulic NON-STOP protection for rocky and heavy soils. The protection force of each tine ranges from 2 205 to 3 307 lb.

Creates ideal soil structure for seeding.

The TERRALAND TN_PROFI chisel plough includes an extra two-row cutter disc section with specially fan-shaped discs with a diameter of 20.5 × 0.2 inches. The special shape of the discs provides efficient crumbling of large clods, covers crop residue, and perfectly levels off the field surface. The interlocking disc arrangement ensures an excellent self-cleaning effect.

TERRALAND TN_PROFI both as a chisel plough and professional subsoiler.

Deep loosening

The TERRALAND TN_PROFI chisel plough in combination with Active-Mix tines and spiked rollers is suitable for deep loosening. The special shape of the tines provides easy soil penetration, and excellent loosening and mixing effect. In one pass, the soil profile is loosened in depth and the soil surface is intensely mixed and levelled.

Subsoil tillage

For even more intense loosening effect.

The TERRALAND TN_PROFI chisel plough with a width of 3 metres is equipped with seven tines with a spacing of 15,7 inches. The TERRALAND TN_PROFI chisel plough with a width of 13,1 feet’ can be equipped with seven or nine tines. The spacing with seven tines is 22.2 inches, with nine tines it is 16.7 inches.

The advantage for you? A longer service life.

The individual parts of the TERRALAND TN_PROFI chisel plough are assembled, not welded. The assembled parts (tines to frames, internal frames to tine beams) have a multiple-times longer service life than when those exposed parts are welded together.

Modify your machine according to your conditions.

Active-Mix tines can be equipped with chisels with a width of 70 mm for intense loosening, or with a width of 40 mm for demanding conditions and deep work. The tine wings undercut the disrupted bottom layer to eliminate clod formation. Chisels and wings are also available in the extremely durable LONG LIFE version (40 mm, 55 mm and 70 mm). The deeper you work, the narrower the chisel should be.

Compact dimensions of the chisel plough, even when equipped with cutter discs.

The TERRALAND TN_PROFI chisel plough is very compact during transport because the cutter disc section hydraulically folds above the main machine frame. An advantage of this design is that the TERRALAND TN_PROFI chisel plough can also work without using the rear section, for example, in extremely waterlogged fields.
