KEY PROPERTIES
A deep cultivator for deep soil cultivation of up to 14 inches, including shallow stubble ploughing after harvest.
Even better loosening and mixing effect.
The models of the FENIX FO_PROFI universal cultivator have tines arranged in four rows. The individual tines are sufficiently spaced, both inside the row and between the individual rows. Therefore, The FENIX FO_PROFI offers high throughput even when working in fields with large quantities of crop residue, organic mass (manure, slurry) or when incorporating catch crop.
Lower tractive resistance and fuel consumption.
The FENIX FO_PROFI universal cultivator excels in the low demands for pulling force thanks to the convenient layout of the individual tines against the soil that reduces tractive resistance. The arrow layout of the tines provides gradual penetration of the individual tines into the soil and excellent processing along the entire machine width.
Maximum adjustment of the machine to the soil conditions.
The FENIX FO_PROFI cultivator now offers several types of protection: shear bolt protection, NON-STOP double-spring horizontal protection (release force of 1 058 lbs) or comfortable hydraulic protection (release force of 1 213 lbs).
Work without the rear packers even when it is wet.
The integrated axle mounted between the working tines enables the machine to work without the rear packer (more tines work after the transport wheels). When it is wet, the packers can easily be deactivated, and soil is cultivated without compaction. This advantage can also be used when preparing soil for winter, when it is usually not required or recommended to roll the soil.
Choose a combination of the levelling section and a leveller.
FENIX FO_PROFI can be equipped with a whole range of working parts in relation to the soil character or customer’s requirements. The four rows of tines are followed with a levelling section that can be equipped with the levelling backfillers or levelling discs, controlled mechanically or hydraulically conveniently from the tractor cabin. For perfect soil levelling, the FENIX FO cultivator can be equipped with the Crushbar leveller after the rear packers.
Allow adjusting the machine to deep loosening or shallow stubble ploughing.
The FENIX FO_PROFI deep cultivator can be equipped with four types of chisels, which let you adjust the machine for deep loosening or shallow stubble ploughing after harvest. A properly selected working chisel type is also important in terms of the character of the soil to be processed, or the season. You can choose from chisels with a width of 3 and 2.5 inches, or LONG LIFE chisels with a width of 3 and 1,5 inches, fitted with carbide plates for higher durability.
Ensure perfect terrain tracing.
The FENIX FO_PROFI cultivator can be equipped with support wheels for perfect terrain tracing. They ensure that the field is evenly cultivated at the set working depth along the entire width of the machine.
A continuous contact with soil under any conditions.
The rear packers of the universal FENIX FO_PROFI cultivator are equipped with a parallelogram that provides perfect terrain tracing and maintains the set working depth. The rear packers are not a part of the support frame as in other competitive machines.
Adjust the working width to the towing vehicle power.
Have you purchased a more powerful tractor or do you need to adjust the machine width to the current conditions and use? The FENIX FO_PROFI models offer the possibility to adjust the working width using the set for assembly/disassembly of the additional side sections.
TECHNICAL DATA
MACHINE DESCRIPTION
For interactive machine description go to https://www.bednar.com/ca/fenix-fo-profi/
